Abans 36000BTU Cooling & Heating R410A Ceiling Suspended 3Phase Non-Inverter Air Conditioner
Model :
ABFC-36CR -
Sold by : ABANS PLC
Rs. 739,990
Rs. 499,490
Monthly Installment Starting
from
Rs.8,325(view details)
or 3 installments of Rs.
166,497
with
Calculate BTU
:
Delivery Time
:
4 - 5 Working Days.
Delivery Fee
:
Rs. 0
We’ll let you know when this item is back in stock.
|
Model |
ABFC-36CR | ||
|
Indoor model |
AUV-36HR4SB1 | ||
|
Outdoor model |
AUW-36H6SD | ||
|
Power supply |
V-ph-Hz | 380-415-3-50 | |
|
Max. input consumption |
W | 4272 | |
|
Max. input current |
A | 8.9 | |
|
Cooling |
Capacity | W | 10550 |
| Capacity | Btu/h | 35997 | |
| Input | W | 3505 | |
| Current | A | 7.1 | |
| EER | W/W | 3.01 | |
|
Heating |
Capacity | W | 11250 |
| Capacity | Btu/h | 38385 | |
| Input | W | 3200 | |
| Current | A | 6.4 | |
| COP | W/W | 3.52 | |
|
Indoor fan motor |
Model | Y7S423B212 | |
| Qty | 1 | ||
| Input | W | 229 | |
| Capacitor | uF | 8 | |
| Speed(Hi/Med/Lo) | r/min | 1260/1130/1000 | |
|
Indoor coil |
Number of rows | 3 | |
| Tube pitch(a)xrow pitch(b) | mm | 21×13.6 | |
| Fin spacing | mm | 1.5 | |
| Fin type | Hydrophilic aluminium | ||
| Tube outside dia.and type | mm | 7.0, innergroove tube | |
| Coil length x height x width | mm | 930×336×40.8 | |
| Number of circuits | 3 | ||
|
Indoor air flow Rated(Hi/Med/Lo) |
m3/h | 1700/1650/1500 | |
|
Indoor air flow Rated(Hi/Med/Lo) |
CFM | 1000/971/882 | |
|
ESP |
Rated | Pa | NA |
| Range | Pa | NA | |
|
Indoor noise level (Hi/Med/Lo) |
dB(A) | 57/54/52 | |
|
Throttle type |
NA | ||
|
Indoor unit |
Dimension (WxDxH) | mm | 1285×680×230 |
| Packing(WxDxH) | mm | 1400x820x350 | |
| Net/Gross weight | kg | 40/47 | |
|
Design pressure |
MPa | 4.8/1.6 | |
|
Drainage water pipe diameter |
mm | DΦ25 | |
|
Refrigerant piping |
Liquid side/ Gas side | mm | Φ9.52/Φ19(3/8"/3/4") |
|
Controller |
Remote control | ||
|
Operation temperature |
1630 | ||
|
Room temperature |
Cooling | 1630 | |
| Heating | 1630 | ||
|
Compressor |
Model | ATH420UC-C9EU | |
| Type | ROTARY | ||
| Brand | Highly | ||
| Capacity | Btu/h | 33711 | |
| Input | W | 3280 | |
| Rated current(RLA) | A | 5.9 | |
| Locked rotor Amp(LRA) | A | 38 | |
| Thermal protector position | INTERNAL | ||
| Capacitor | μF | / | |
| Refrigerant oil | ml | α68HES-H/2600 | |
|
Outdoor fan motor |
Model | Y6S696D511 | |
| Old Model | / | ||
| Qty | 1 | ||
| Input | W | 160 | |
| Capacitor | μF | ||
