FEATURES
Fresh Air
After a certain time period, the quality of room air tends to decrease. This is due to the presence of CO2 and foul odours such as sweat, smoke, etc. The Fresh Air function circulates the polluted indoor air outside the room and then redistributes fresh air from the outdoors.
Auto Clean
One of the primary causes of the foul odours that emit from an air conditioner is mold and bacterial growth on the evaporator. The Auto Clean function prevents this by automatically cleaning the evaporator and inhibiting the proliferation of bacteria and mold inside the air conditioner.
Nano Silver Cross Fan
The nano silver coating on the indoor cross fan inhibits bacterial growth for cleaner, healthier air.
Multi-_lter System
The Multi-Filter System, which comprises of Nano Silver, Active Carbon, Bio, and Vitamin C _lters, maintains the pristine quality of indoor air by e_ciently absorbing dust and eliminating di_erent strains of bacteria.
Anti-dust Filter
This _lter catches the most miniscule dust particles to produce cleaner air. Also, it can be easily washed and cleaned.
Active Carbon Filter
Absorbs small dust particles, smoke, allergens, and harmful chemical gases such as Ammonia (NH3) and Formaldehyde (HCHO).
Sleep Mode
The Sleep Mode function automatically increases or decreases the setting temperature within the _rst two hours of activation. This provides the user the most comfortable temperature to sleep in and conserves energy as well.
Self-diagnosis and Auto-protection Function
The air conditioner automatically detects errors with its microcomputer chips and indicates them on a LED display.
Turbo
The Turbo function produces cooling comfort in the shortest timeframe possible.
Auto Restart
This mode allows the air conditioner to automatically restart with the same settings that were put in place at the last time that you used it.
Strong Dehumidi_cation
Maintains a comfortable level of humidity throughout the room without reducing the overall setting temperature.
Inner Grooved Copper Tube
Compared to conventional smooth copper tubes, this mechanism enhances the heat-exchange e_ciency level upto %50.
Low Noise Air Flow System with Large Diameter Cross Fan
Reduces the noise of the indoor air conditioner unit without decreasing the strength of the air _ow.
Valve Protection Cover
Prevents water leakage, and protects the valves from damage.
Temperature Compensation (Heating Mode)
Reduces temperature _uctuations so that you can experience a balanced temperature during the Heating Mode.
Anti-cold Air Function
Prevents frigid cold air from blowing directly onto the user.
Hydrophilic Aluminium Fin
Allows the condensate water to _ow freely between the _ns and improves the overall cooling e_ciency. Also, enhances the heating e_ciency by accelerating the defrosting process.
Condenser Heating Kits
Prevents the condenser from freezing in low temperatures, so that the air conditioner can run the Heating Mode e_ciently.
Low Ambient Kit
The unit can be operated in Cooling Mode in low ambient temperature conditions.
LED Display
Helps the user to monitor and operate the unit clearly and easily.
Soft Start Kit
Safeguards the air conditioner against electrical damage in the event of severe voltage _uctuations.
Easy Wiring Connection
Allows you to easily connect both the indoor and outdoor units.
Compressor Heating Kits
Warms up the compressor when it gets frozen in low temperature conditions.
Quick Connector
Allows users to easily connect the specially designed copper pipe and signal wire connectors, saving them time and money.
Model |
ABLG-30CR |
|
Ratings |
|
|
Cooling Capacity |
W |
8200 |
Heating Capacity |
W |
8000 |
Power Input-Cooling |
W |
2720 |
Power Input-Heating |
W |
2490 |
Moisture Removal |
L/H.r |
2.2 |
Air Circulation |
CMH Max |
1200 |
EER for Cooling |
W/W |
3.01 |
COP for Heating |
W/W |
3.21 |
Energy Consumption |
kWh / year |
1360 |
Energy Class for Argentina |
Cooling |
B |
Energy Class for Argentina |
Heatling |
C |
Refrigerant |
R410A |
|
Refrigerant volumn |
g |
1950 |
Indoor Unit Noise Level |
High(dB (A)) |
45 |
Low(dB (A)) |
42 |
|
Outdoor Unit Noise Level |
dB (A) |
58 |
Power Supply |
|
|
Voltage, Frequency, Phase |
220-240V/50Hz |
|
Rated Current |
Cooling (A) |
12.1 |
Heating (A) |
11.2 |
|
LRA |
A |
65.6 |
System |
|
|
Compressor type |
Rotary |
|
Compressor Model No. |
PA311X3CS-4MTL |
|
Compressor MFG |
GMCC |
|
Expansion Device |
flow restrictor |
|
Evaporator |
Copper tube and Aluminum Fin |
|
Condenser |
Copper tube and Aluminum Fin |
|
Evaporator |
|
|
Connecting Pipe Diameter |
|
|
Liquid Pipe |
inch |
3/8 |
Gas Pipe |
inch |
5/8 |
Maximum connection pipe lenght |
m |
15 |
Maximum height difference |
m |
5 |
Features |
|
|
Display on Front Panel |
LED |
|
LCD Wireless Remote Controller |
Yes |
|
Removable and washable Panel |
Yes |
|
High density Filter |
Yes |
|
Active Charcoal Filter |
Optional |
|
Electrostatic Filter |
Optional |
|
HEPA Filter |
Optional |
|
LTC Filter |
Optional |
|
Catechin filter |
Optional |
|
Negative ion filter |
Optional |
|
Photic Catalyst filter |
Optional |
|
Vitamin-C filter |
Optional |
|
Dimmer |
Yes |
|
24 Hours Timer |
Yes |
|
Timer ON/OFF |
Yes |
|
3 Speed and Auto Indoor Fan Control |
Yes |
|
Horizontal Auto Swing Louver |
Yes |
|
Manual Adjustable Vertical Louver |
Yes |
|
Top Down Horizontal louvers features for cooling mode |
Yes |
|
Sleep function |
Yes |
|
Smart sense function |
Yes |
|
Super function |
Yes |
|
Compressor Indicator |
Yes |
|
Auto Restart |
Yes |
|
Auto Defrost |
Yes |
|
Dehumidification function |
Yes |
|
Cold air protection |
Yes |
|
Other(VQ panel) |
|
|
Net Dimensions WxHxD (mm) |
Indoor Unit |
1148×315×236 |
Outdoor Unit |
860x650x310 |
|
Net Weight (Kg) |
Indoor Unit |
14.5 |
Outdoor Unit |
49 |
|
Packing Dimensions WxHxD (mm) |
Indoor Unit |
1210×390×315 |
Outdoor Unit |
995x730x445 |
|
Gross Weight (Kg) |
Indoor Unit |
17 |
Outdoor Unit |
51 |
|
Loading Capacity (20'/40'/40'HC ) without pipe |
62/128/145 |
|
Loading Capacity (20'/40'/40'HC ) with pipe |
62/128/145 |
